TFS Tinplate Coil Electrolytic Tinplate Sheet T4 T5 DR7 DR8 DR9 Tinplate Coils Sheets

TFS Tinplate Coil Electrolytic Tinplate Sheet T4 T5 DR7 DR8 DR9 Tinplate Coils Sheets

JIS Food Can Tinplate Coil

Tinplate Sheet Coils DR7

Cake Can Closure Tinplate

Place of Origin:

China

Brand Name:

QuanJiang

Certification:

GB

Model Number:

MR,SPCC

Contact Us

Request A Quote
Product Details
Hardness::
T1 T2 T3 T4 T5 DR8 DR9
Thickness::
0.15-0.50mm
Tin Coating::
1.1/1.1,2.0/2.0; 2.8/2.8,5.6/5.6, Etc. Or Customerized
Application::
Sardine Can, Tuna Can, Food Can, Fruit Can, Bean Can
Width::
700-1000mm,800mm, 820mm, 838mm,876mm Or Customized
Temper::
TS230, TS245, TS260,TS275, TS290,TH415,TH435, TH520, TH550, TH580, TH620
Length::
600-1200mm Or As Coils
Useage;:
Aerosol Can, Sardines Can, Tuna Can , Vergetabl Can, Fruit Can Paint Can
Payment & Shipping Terms
Minimum Order Quantity
25tons
Price
Negotiated
Packaging Details
Seaworthy Standard with wooden pallet, corner protected. by sheet or coils according customer's requires.
Delivery Time
negotiated
Payment Terms
T/T
Supply Ability
50000MT/Month
Product Description

TFS Tinplate Coil Electrolytic Tinplate Sheet

Electrolytic ETP is characterized by its beautiful metallic luster. Products with various kind

 of surface roughness are produced by selecting the surface finish of the substrate steel sheet.

Features of TFS Products

Excellent paint adhesion



TFS has excellent paint adhesion properties that far surpass those of ETP, allowing its use for making DRD cans and adhesive bonded cans.

Excellent heat resistance



High-temperature baking causes neither discoloration nor deterioration in material properties.

Excellent resistance to Sulphur Blackening



The metallic chromium in TFS has excellent sulphide resistance property when canning protein-rich foodstuff such as fish. TFS compensates for the expensive sulphur resistant lacquer.

Excellent filiform rust resistance



TFS has a excellent under film corrosion resistance.

Excellent alkali resistance



The coating in TFS is not amphoteric. Alkaline products such as detergents and dispersion colours can be packed in TFS with advantage.

Different Features between TFS and ETP

Appearance

Even when the same surface finish as ETP is applied to the substrate steel sheet, it provides the unique surface luster characteristic of metallic chromium.

Corrosion resistance

As it has excellent corrosion resistance after painting, it is generally used with both surfaces painted. It can also be used with the internal surface unpainted, depending on the contents.

Solderability

TFS is not compatible with soldering.

Weldability

Although TFS can be welded when the metallic coating layers are removed, its weldability is inferior to ETP.

Coating weights

Unlike the multiplicity of coating weights with tin, only one standardized chromium-coated product is manufactured.

TFS Tinplate Coil Electrolytic Tinplate Sheet T4 T5 DR7 DR8 DR9 Tinplate Coils Sheets 0TFS Tinplate Coil Electrolytic Tinplate Sheet T4 T5 DR7 DR8 DR9 Tinplate Coils Sheets 1

Applications of Tinplate and TFS
ETP is primarily used for packaging foodstuffs and beverages, but it is also used in containers for oils, grease, paints, polishes, chemicals and many other products. Aerosol containers and caps and closures are also made from ETP.
TFS are most frequently used for can tops, screw and lug caps, snap and press-on closures and shallow-drawn food cans.

TFS Tinplate Coil Electrolytic Tinplate Sheet T4 T5 DR7 DR8 DR9 Tinplate Coils Sheets 2TFS Tinplate Coil Electrolytic Tinplate Sheet T4 T5 DR7 DR8 DR9 Tinplate Coils Sheets 3

PROCESS

TFS Tinplate Coil Electrolytic Tinplate Sheet T4 T5 DR7 DR8 DR9 Tinplate Coils Sheets 4



TFS Tinplate Coil Electrolytic Tinplate Sheet T4 T5 DR7 DR8 DR9 Tinplate Coils Sheets 5
