Precision-Gauge Electrolytic Tin Plate Coils for Energy Drink Cans - 0.16-0.35mm Multi-Surface Finishes

Place of Origin:

China

Brand Name:

QuanJiang

Certification:

SGS

Model Number:

TFS / tin free steel

Request A Quote

Product Details

Hardness::

T1,T2,T3,T4,T5,DR7,DR8,DR9

Material::

Prime MR/ SPCC Tinplate

Application:

Tin Can Top, Screw, Lug Cap, Snap, Press-on Closures And Shallow-drawn

Thickness::

0.15mm-0.4mm Or Customized

Surface::

Bright,Stone,Matte, Sliver, Rough Stone

Width::

660mm-1000mm Or Customized

Type::

Tinplate Sheet Or Tinplate Coil

Temper::

TS230, TS245, TS260,TS275, TS290,TH415,TH435, TH520, TH550, TH580, TH620

Usage::

Mild Can,dairy Can ,aerosol Can, Tuna Can, Meat Can, Pinapple Can Etc

Package::

Thin Plastic Film + Rust-proof Paper+metal Cover+metal Angles+straps+pallet

Payment & Shipping Terms

Minimum Order Quantity

25tons

Price

Negotiated

Packaging Details

thin plastic film + rust-proof paper+metal cover+metal angles+straps+pallet

Delivery Time

negotiated

Payment Terms

T/T

Supply Ability

50000 Metric Ton

SPTE Tinplate / Coil The Superior Material for Tin Can Energy Drink Packaging

Get Best Price

Video

1030mm ETP Beverage Can SPTE Tinplate 0.22mm 0.18mm 0.17mm Thickness rust-resistance luster tinplate

Get Best Price

Video

Food Grade SPTE Tinplate Coils For Round Can Cover Tin Lids And Beverage Can Ends

Get Best Price

Video

Discover The Superior Properties Of Tinplate And TFS For Consumer And Industrial Packing

Get Best Price

+8618321408860-021-56922400

quanye@spte.cn

+86-021-56922411

Contact Now

Product Description

Precision-Gauge Electrolytic Tin Plate Coils for Energy Drink Cans - 0.16-0.35mm Multi-Surface Finishes

Name: Precision-Gauge Electrolytic Tin Plate Coils for Energy Drink Cans - 0.16-0.35mm Multi-Surface Finishes
Brand: SHANGHAI QUANYE METAL PACKAGING MATERIALS CO.,LTD
SKU: TFS / tin free steel
Price: 499.01 USD
Availability: InStock

QuanJiang's Electrolytic Tin Plate (ETP) & Tin-Free Steel (TFS) Coils redefine can manufacturing for carbonated and energy drinks. Precision-engineered at 0.16-0.35mm thickness with bright, stone, silver, and matte finishes, these SGS-certified coils combine extreme corrosion resistance, high-speed formability, and vibrant print readiness for demanding beverage applications.

Breakthrough Performance Features

✔ Pressure-Tested Integrity

Withstands 90psi internal pressure (carbonation stability)
TS260-TH550 hardness for seam integrity

✔ Surface-Optimized Finishes

Bright (95+ GU): Premium shelf appeal
Matte (0.8-1.2µm Ra): Scratch resistance during filling
Stone (1.5-2.5µm Ra): Enhanced paint adhesion

✔ Chemistry-Resistant Design

pH 2.5-4.5 compatibility (citric/phosphoric acids)
Zero flavor migration

Technical Specifications

Parameter	Specifications
Material	Prime MR/SPCC Steel
Thickness Range	0.16–0.35mm (±0.005mm)
Width	660–1,000mm (slitting tolerance ±0.5mm)
Coating Options	2.0/2.0 – 5.6/5.6 g/m² (differential available)
Temper Grades	T2-T5, DR7-DR9
Peak Pressure	0.2mm: 75psi; 0.35mm: 120psi

Competitive Advantages

Filling Line Efficiency: 2,000 cans/min compatibility
Print Superiority: 25% ink reduction vs. standard TFS
Supply Chain Power: 50,000 MT/month; 25-ton MOQ
Sustainability: 100% recyclable; 88% recycled content

Energy Drink Application Matrix

Thickness	Can Component	Performance Edge
0.16mm	Easy-open ends	22% weight reduction
0.19mm	Slim can bodies	80psi burst strength
0.20mm	Standard lids	Optimal seam weldability
0.35mm	Large format (500ml)	Vibration resistance

FAQ

Q: Why TFS over ETP for energy drinks?

A: 30% better paint adhesion and superior acid resistance at lower cost.

Q: Minimum thickness for CO² containment?

A: 0.19mm DR8 maintains seal at 4.0vol CO².

Q: Certification for US FDA compliance?

A: Meets FDA 21 CFR 175.300 – extractables <50ppb.

Q: Lead time for custom widths?

A: 18 days with SGS corrosion test reports.

Q: Recycling compatibility?

A: Fully EAF-ready – chromium layer vaporizes at 1,600°C.
