Corrosion Resistance 0.18mm Thickness Painted Tinplate / TFS Sheets for Metal Can
| TINPLATE |
TINPLATE Tinplate is a thin steel coated with tin. Tinplate is characterized by its beautiful metallic luster as well as excellent properties in corrosion resistance, solderability and weldability. |
| TIN FREE STEEL (TFS) |
TIN FREE STEEL( TFS) TFS is electrolytic chromium coated steel, which has a superior paintability and paint adhesion. Since TFS has an excellent sulfide stain resistance, it can be applied to food usage with inside coating. |
1.ETP
|
Former Coating Designation |
Coating Weight Code |
Nominal Coating Weight(g/m2) |
Minimum Average Coating weight(g/m2) | |
|
Equally Coated |
10# | 1.1/1.1 | 1.1/1.1 | 0.9/0.9 |
| 20# | 2.2/2.2 | 2.2/2.2 | 1.8/1.8 | |
| 25# | 2.8/2.8 | 2.8/2.8 | 2.5/2.5 | |
| 50# | 5.6/5.6 | 5.6/5.6 | 5.2/5.2 | |
| 75# | 8.4/8.4 | 8.4/8.4 | 7.8/7.8 | |
| 100# | 11.2/11.2 | 11.2/11.2 | 10.1/10.1 | |
|
Differentially Coated |
25#/10# | 2.8/1.1 | 2.8/1.1 | 2.5/0.9 |
| 50#/10# | 5.6/1.1 | 5.6/1.1 | 5.2/0.9 | |
| 50#/25# | 5.6/2.8 | 5.6/2.8 | 5.2/2.5 | |
| 75#25# | 8.4/2.8 | 8.4/2.8 | 7.8/2.5 | |
| 75#50# | 8.4/5.6 | 8.4/5.6 | 7.8/5.2 | |
| 100#/25# | 11.2/2.8 | 11.2/2.8 | 10.1/2.5 | |
| 100#/50# | 11.2/5.6 | 11.2/5.6 | 10.1/5.2 | |
| 100#/75# | 11.2/8.4 | 11.2/8.4 | 10.1/7.8 |
2. TFS
| Metallic Chromium Layer(one side) | Chromium Oxide Layer(one side) | ||
|
Minimum Average Coating Weight |
Maximum Average Coating Weight |
Minimum Average Coating Weight |
Maximum Average Coating Weight |
| 50mg/m² | 150mg/m² | 5mg/m² | 35mg/m² |
Application:
Tinplate is widely used for the packaging of products. Such as food cans,
beverage cans, pet cans, closures,general line cans and so on.
| Classification | Main Applications | |
| Food Cans | Cans for preserved food | Preserved fishery and agricultural products, etc. |
| Cans for beverages | Juice, carbonated soft drinks, other beverages, etc. | |
| General Cans | 4L Cans | Automobile oil, mechanical oil, etc. |
| 18L Cans | Industrial containers for paint and oils | |
| Pail Cans | Industrial containers for paint and oils | |
| Aerosol Cans | Cosmetics, butane gas, pesticide, etc. | |
| Crown | Crown Caps | Liquor, soft drink bottle caps |
Production Process
HONOR CERTIFICATE
FAQ
1. how can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment;
2.what can you buy from us?
Printed Tinplate,Tinplate LID,Tin plate sheet,Tinplate coil
3.why should you buy from us not from other suppliers?
Technical team leader who worked as superior engineers in Japan Fuji Tinplate-printing
enterprise more than 21 years;
Five full automatic newest FUJI micro-HD full colors Iron-printing Lines;
Long-terms good relationship with famous tin mills.
4. what services can we provide?
Accepted Delivery Terms: FOB,
Accepted Payment Currency:USD,CNY;
Accepted Payment Type: T/T.
Language Spoken:English,Chinese
Send your inquiry directly to us
