Place of Origin:
China
Brand Name:
QuanJiang
Certification:
MILL CERTIFICATE
Model Number:
tinplate coil
Contact Us
Customizable Tinplate Coil Printing Sheet for Different Food Can Production
Good adaptability to food packaging:
1. Corrosion resistance: The tin-plated layer on the surface of tinplate can effectively prevent iron from reacting with acidic and alkaline components in food and oxygen and moisture in the external environment, protect the quality and safety of food, and extend the shelf life of food. For example, in canned fruit or pickled food with high acidity, tinplate can resist corrosion well.
2. Good sealing: Tinplate is easy to seal, such as welding, crimping and other operations. Good sealing can prevent food from exchanging with the outside air, avoid food oxidation, deterioration, moisture or microbial contamination, which is especially important for food that needs to be stored for a long time.
3. Mechanical properties: It has certain strength and toughness, and can withstand various pressures, collisions and extrusions during the production, transportation, storage and sales of food cans. Even when stacked or subjected to certain external force impact, it can maintain the integrity of the can body and protect the internal food.
Printing adaptability:
The surface of tinplate is relatively flat and smooth, suitable for a variety of printing methods, such as offset printing, gravure printing, etc. Printing ink has good adhesion on the tinplate surface, which can ensure the clarity, vividness and durability of the printed patterns and text. This allows the customized printed content to maintain good visual effects throughout the life cycle of the food can and enhance the image of the product.
Application in the production of different food cans:
1. Canned food cans
Such as meat cans, fish cans, vegetable cans, etc. The customizable tinplate roll printing plate can adjust the thickness according to the type of can to ensure strength, while printing attractive patterns and detailed product information. For example, meat cans may print attractive pictures of meat, and vegetable cans may emphasize the freshness of vegetables.
2. Beverage cans
For carbonated beverage cans, sufficient strength is required to withstand the internal pressure, and the customizable tinplate roll printing plate can provide the right thickness. At the same time, in terms of printing, colorful and dynamic patterns can be customized to attract consumers, such as popular beverage brand logos and fashionable design elements.
3. Sauce and condiment cans
These cans are relatively small, and the tinplate roll printing plate of the right size can be customized. In printing, the taste characteristics of the product can be highlighted, such as pepper patterns for pepper sauce jars, vanilla patterns for seasoning jars, etc., and information such as instructions for use can be easily printed.
Product | Tinplate Sheet |
Standard | ASTM A623, EN 10203, GB2520-2000,JISG3303-2002 and DINEN10202-2001 |
Material | MR SPCC |
Thickness | 0.15- 0.45mm (tolerance -/+0.01 mm) |
Width | 700~1050mm (Tolerance: 0~3mm) or |
Cutting Length | 700~1150mm (Tolerance: 0~3mm) or as coils |
Annealing | BA & CA |
Temper | T1 T2 T3 T4 T5 DR7 DR8 DR9 TH550 TH580 TH620 TH660 |
Tin Coating | 1.1/1.1 2.0/2.0 2.8/2.8 2.8/5.6 5.6/5.6 8.4/8.4 11.2/11.2 g/㎡ |
Surface finish | Bright, Stone, Silver, Matt |
Coil Diameter | ID 420/ 508/610mm, OD from 1,000 to 1,250m |
Coil Weight | 3~10 MT |
Package | Seaworthy Standard with wooden pallet, corner protected. by sheet or coils according customer's requires. |
Applications | Metal package usage like paint, chemical can,aerosol can and different food can production, Also battery,electric cable and other industries |
PACKING
OUR COMPANY
Shanghai Quanjiang Industrial Co.,ltd is a large-scale enterprise integrating manufacturing and sales
( international export). Established in 2001. With an area of more than 40 000 square meters. It's
located in Shanghai,China, We has advanced production equipment, equipped with pushing
machine, press, large heat treatment furnace,chamfering machine,sawing machine,large
sandblasting machine and other key equipment and a variety of testing instruments
CERTIFICATE
