DR8 DR9 ETP Electrolytic Tin Plate Corrosion Resistance formability strength tinplate SPTE TFS

DR8 DR9 ETP Electrolytic Tin Plate Corrosion Resistance formability strength tinplate SPTE TFS

ETP Electrolytic Tin Plate

DR9 Electrolytic Tin Plate

SPTE Coating Electrolytic Tin Plate

Place of Origin:

China

Brand Name:

QuanJiang

Model Number:

MR,SPCC

Contact Us

Request A Quote
Product Details
Width::
600~1010mm
Hardness::
TH50 TH52 TH55 TH57 TH 61 TH65 T550 T580 T620
Type::
Tinplate Coil/ Sheet
Package::
Iron Guard With Fumigation Wooden Pallet
Material::
MR Prime Tinplate
Thickness::
0.18mm-0.45mm
Length:
600mm-1100mm Or Coil
Tin Coating::
1.1/1.1, 2.8/2.8,5.6/5.6, 8.4/5.6, 11.2/11.2 Etc..
Surface::
Bright,Stone,Matte, Sliver,Stone Rough
Application::
Aerosol Can, Sardines Can, Tuna Can , Vergetabl Can, Fruit Can Paint Can
Payment & Shipping Terms
Minimum Order Quantity
25tons
Price
Negotiated
Packaging Details
iron guard with fumating wooden pallets, as customer's requirement
Delivery Time
negotiated
Payment Terms
T/T
Supply Ability
50000MT/Month
Product Description

Corrosion Resistance formability strength tinplate SPTE TFS

Tinplate Products features

Excellent Formability & Strength

By selecting a proper temper grade, appropriate formability is obtained for various applications as well as the required strength after forming.

Excellent Corrosion Resistance

By selecting a proper coating weight, appropriate corrosion resistance is obtained against container contents.

Excellent Paintability & Printability

Printing is beautifully finished using various lacquers and inks.

Excellent Solderability & Weldability

TIN PLATE is widely used for making various types of cans by soldering or welding.

Beautiful Appearance

Electrolytic ETP is characterized by its beautiful metallic luster. Products with various kinds of surface roughness are produced by selecting the surface finish of the substrate steel sheet.

DR8 DR9 ETP Electrolytic Tin Plate Corrosion Resistance formability strength tinplate SPTE TFS 0
Steel Type tinplate /SPTE coating weight 1.1/1.1,best price
Temper(BA&CA) T1 - T5 BA and CA both
Coating 1.1~11.2g/m2
Thickness and tolerance 0.15~0.50mm(Tolerance: _+0.01 mm)
Width & tolerance 600~1050mm (Tolerance: 0~3mm)
Cut length & tolerance 650~1200mm (Tolerance: 0~3mm ) or coils
Coil inside diameter 420/508mm
Coil Weight 3~10 MT
Passivation 311
Oiling DOS
Surface Finish Bright, Stone, Silver, Matte
Packaging Seaworthy Standard with wooden pallet
Standards Available GB/T2520, JIS G3303, ASTM A623M & EN10202
Temper Hardness Guarantee (HR30T)HR30T Applications
T1 49±3 Nozzles, spouts, closures, and deep drawing.
T2 52±3 Rings and plugs, pie pans, closures, shallow drawn and specialized can parts.
T2.5 55±3 Battery can bodies, small can ends and bodies.
T3 57±3 Can ends and bodies, large diameter closures, crown caps.
T4 61±3 Can ends and bodies, crown caps and small screw closures.
T5 65±3 Can ends and bodies for non corrosive products.
DR-8 73 ± 3 small diameter round can bodies and ends
Surface finish Nominal surface roughness (um Ra) Characteristic
Bright finish ≤Q0.35 Glazed surface obtained after melting treatment of electrotinned smooth raw materail strip with extremely fine rubstone fingure by processing.
Stone finish 0.25~0.60 Glazed surface obtained after melting treatment of electrotinned smooth raw materail stripfeaturing certain rubstone figures.
Silver finish 0.50~1.00 Glazed surface obtained after melting treatment of electrotinned smooth raw material strip with rough matt furface.
Matte finish 0.80~2.50 Matt surface of general matt raw material strip without melting treatment.
Classification Main Applications
Food Cans Cans for preserved food Preserved fishery and agricultural products, etc.
Cans for beverages Juice, carbonated soft drinks, other beverages, etc
General Cans 4L Cans Automobile oil, mechanical oil, etc.
18L Cans Industrial containers for paint and oils
Pail Cans Industrial containers for paint and oils
Aerosol Cans Cosmetics, butane gas, pesticide, etc.
Crown Crown Caps Liquor, soft drink bottle caps
Others Electronic Components Electronic items such as TV, tuner cases, etc.
Electronic Jar Electronic items such as electric cookers, etc.
Others Other shell of batteries, toys, stationeries, etc.

Packaging

For coils/strips
Anti-rust paper +metal cover +corner protected +wood pallet.

For sheets
Thin plastic film +rust-proof paper +metal cover +metal angles + straps + pallet.

DR8 DR9 ETP Electrolytic Tin Plate Corrosion Resistance formability strength tinplate SPTE TFS 1

DR8 DR9 ETP Electrolytic Tin Plate Corrosion Resistance formability strength tinplate SPTE TFS 2

Application of Tinplate

Tinplate Applications

Tinplate is applied to various containers such as food, beverage, artistic containers

and electric parts.

TFS Applications

Excellent paint adhesion makes itself the most suitable material for making food can,

crown,artistic can and general can with painting.

DR8 DR9 ETP Electrolytic Tin Plate Corrosion Resistance formability strength tinplate SPTE TFS 3DR8 DR9 ETP Electrolytic Tin Plate Corrosion Resistance formability strength tinplate SPTE TFS 4

DR8 DR9 ETP Electrolytic Tin Plate Corrosion Resistance formability strength tinplate SPTE TFS 5

PARTNER

DR8 DR9 ETP Electrolytic Tin Plate Corrosion Resistance formability strength tinplate SPTE TFS 6

CERTIFICATE

DR8 DR9 ETP Electrolytic Tin Plate Corrosion Resistance formability strength tinplate SPTE TFS 7

FAQ

Information Required with orders and inquirys

Orders and inquiried shall be accompanied by the following information.

1. products name and grade

2.coaing and mass( for Tinplate only),temper grade,finish, and products size.

3.rolling direction

4.quantity

5.application and delivery date

6.number of sheets per packaging( for cut to length products)

7.inside diameter amd maximum acceptable unit coil weight (for coils products).

8.film type,color, contents,and other details of use and environment.

9.other special requirements,if any.

TEST equipment of TINPLATE
