0.2mm 0.21mm 0.22mm 0.23mm 0.25mm Tinplate For Tin Can Food Packaging Tinplate SPTE TFS
TINPLATE
Tinplate is a thin steel coated with tin. Tinplate is characterized by its beautiful metallic
luster as well as excellent properties in corrosion resistance, solderability and weldability.
TIN FREE STEEL( TFS)
TFS is electrolytic chromium coated steel, which has a superior paintability and paint
adhesion. Since TFS has an excellent sulfide stain resistance, it can be applied to
food usage with inside
|
Advantages Tinplate Packaging |
|
Health Provide excellent and non-toxic barrier properties to protect food products from impurities, bacteria, moisture, light, and odours. |
|
Safe Low weight and high strength make food cans easy to ship and store. |
|
Environmental Offer 100% recyclability; and significant cost benefits compared with aluminum. |
TINPLATE FEATURES
TFS FEATURES
Applications of Tinplate and TFS
ETP ETP is primarily used for packaging foodstuffs and beverages, but it is also used in
containers for oils, grease, paints, polishes, chemicals and many other products. Aerosol
containers and caps and closures are also made from ETP.
TFS TFS are most frequently used for can tops, screw and lug caps, snap and
press-on closures and shallow-drawn food cans.
Miscellaneous
Electrodes, Cable tape, Magnetic screen covers, etc.
Automotive oil filters, Automotive air filters, Gaskets, etc.
Gas meter internal components, Heat exchangers, cookware, shelving, etc.
| Q/BQB 450-2009 | JIS G3303:2008 | ASTM A623M-08 | DIN EN 10202:201 | ISO 11949:1995 | GB/T 2520-2008 | GB/T 2520-2000 | |
| Single cold-reduced | - | T-1 | T-1(T49) | TS230 | TH50+SE | T-1 | TH50+SE |
| T1.5 | - | - | - | - | T-1.5 | - | |
| T-2 | T-2 | T-2(T53) | TS245 | TH52+SE | T-2 | TH52+SE | |
| T-2.5 | T-2.5 | - | TS260 | TH55+SE | T-2.5 | TH55+SE | |
| T-3 | T-3 | T-3(T57) | TS275 | TH57+SE | T-3 | TH57+SE | |
| T-3.5 | - | - | TS290 | - | T-3.5 | - | |
| T-4 | T-4 | T-4(T61) | TH415 | TH61+SE | T-4 | TH61+SE | |
| T-5 | T-5 | T-5(T65) | TH435 | TH65+SE | T-5 | TH65+SE | |
| Double cold-reduced | DR-7M | - | DR-7.5 | TH520 | - | DR-7M | - |
| DR-8 | DR-8 | DR-8 | TH550 | T550+SE | DR-8 | T550+SE | |
| DR-8M | - | DR-8.5 | TH580 | T580+SE | DR-8M | T580+SE | |
| DR-9 | DR-9 | DR-9 | TH620 | T620+SE | DR-9 | T620+SE | |
| DR-9M | DR-9M | DR-9.5 | - | T660+SE | DR-9M | T660+SE | |
| DR-10 | DR-10 | - | - | T690+SE | DR-10 | T690+SE |
APPLICATION
