Prime Electrolytic Tinplate 0.14mm,0.17mm, 0.21mm 0.30mm 876mm 838mm 842mm DR8 TH550 TS260 TS275 Electrolytic Tin Plate

Prime Electrolytic Tinplate 0.14mm,0.17mm, 0.21mm 0.30mm 876mm 838mm 842mm DR8 TH550 TS260 TS275 Electrolytic Tin Plate

Metal Packaging Electrolytic Tin Plate

Anti Oxidation Electrolytic Tinplate

Alkali Resistance Electrolytic Tinplate

Place of Origin:

China

Brand Name:

QuanJiang

Certification:

MILL CERTIFICATE

Model Number:

MR 842mm 800mm TFS tinplate

Contact Us

Request A Quote
Product Details
Width::
842mm 800mm 929mm 900mm 730mm 960mm Or Customized
Hardness::
DR8CA,DR9CA, DR8,DR9,T5BA,T5CA, DR7CA,TH550,T4CA,T4BA, L T5CA K,T3BA, T2.5BA, T2.5CA,
Package::
Iron Guard With Fumigation Wooden Pallet
Material::
MR Prime Tinplate
Thickness::
0.14mm 0.17mm 0.21mm 0.30mm 0.32mm Or Customized
Tin Coating::
1.1/1.1, 2.8/2.8,5.6/5.6, Etc. Or Customerized
Surface::
Bright,Stone,Matte, Sliver, Rough Stone
Application::
Aerosol Can, Sardines Can, Tuna Can , Vergetabl Can, Fruit Can Paint Can
Payment & Shipping Terms
Minimum Order Quantity
25tons
Price
Negotiated
Packaging Details
Seaworthy Standard with wooden pallet, corner protected. by sheet or coils according customer's requires.
Delivery Time
negotiated
Payment Terms
T/T
Supply Ability
50000MT/Month
Product Description

Prime Electrolytic TinplateDR8 TH550  Electrolytic Tin Plate
Electrolytic Tin Plate English Abbreviations: SPTE. It refers to cold rolled low
carbon thin steel plate or steel strip coated with commercial pure tin on both sides.

Excellent paint adhesion

TFS has excellent paint adhesion properties that far surpass those of ETP, allowing its use for making DRD cans and adhesive bonded cans.

Excellent heat resistance

High-temperature baking causes neither discoloration nor deterioration in material properties.

Excellent resistance to Sulphur Blackening

The metallic chromium in TFS has excellent sulphide resistance property when canning protein-rich foodstuff such as fish. TFS compensates for the expensive sulphur resistant lacquer.

Excellent filiform rust resistance

TFS has a excellent under film corrosion resistance.

Excellent alkali resistance

The coating in TFS is not amphoteric. Alkaline products such as detergents and dispersion colours can be packed in TFS with advantage.

Prime Electrolytic Tinplate 0.14mm,0.17mm, 0.21mm 0.30mm 876mm 838mm 842mm DR8 TH550 TS260 TS275  Electrolytic Tin Plate 0Prime Electrolytic Tinplate 0.14mm,0.17mm, 0.21mm 0.30mm 876mm 838mm 842mm DR8 TH550 TS260 TS275  Electrolytic Tin Plate 1

MaterialMR
Thickness0.14 to 0.5mm
Width660 to 1020 mm
Length600 to 1200 mm or Coils
Tin coating2.8g/2.8g, 5.6g/5.6g, 2.8/5.6,2.0/2.0 g/m² or according to customer'srequirement
TemperT2, T2.5, T3, T3.5, T4,T5 ,DR7,DR7M,DR8
AnnealingCA(Continuous annealing) and BA(Batch annealing)
SurfaceBright/Stone/Silver finish with passivation treatment; DOS oil
MOQ25 tons or one container
PaymentT/T
Reference standardGB/T 2520-2008, JIS G3303-2008 ,DIN EN 10203-1991, ASTM A623M-2011
Applications:Widely used for metal packaging industry.
Such as making cans for food, tea, oil, paints, chemicals, aerosol, gifts, printing

Product Show
Prime Electrolytic Tinplate 0.14mm,0.17mm, 0.21mm 0.30mm 876mm 838mm 842mm DR8 TH550 TS260 TS275  Electrolytic Tin Plate 2Prime Electrolytic Tinplate 0.14mm,0.17mm, 0.21mm 0.30mm 876mm 838mm 842mm DR8 TH550 TS260 TS275  Electrolytic Tin Plate 3
Application:
Tinplate is widely used for the packaging of products. Such as food cans,
beverage cans, pet cans, closures,general line cans and so on.

ClassificationMain Applications
Food Cans Cans for preserved foodPreserved fishery and agricultural products, etc.
Cans for beveragesJuice, carbonated soft drinks, other beverages, etc.
General Cans4L CansAutomobile oil, mechanical oil, etc.
18L CansIndustrial containers for paint and oils
Pail CansIndustrial containers for paint and oils
Aerosol CansCosmetics, butane gas, pesticide, etc.
CrownCrown CapsLiquor, soft drink bottle caps
OthersElectronic ComponentsElectronic items such as TV, tuner cases, etc.
Electronic JarElectronic items such as electric cookers, etc.
OthersOther shell of batteries, toys, stationeries, etc.

Prime Electrolytic Tinplate 0.14mm,0.17mm, 0.21mm 0.30mm 876mm 838mm 842mm DR8 TH550 TS260 TS275  Electrolytic Tin Plate 4
Prime Electrolytic Tinplate 0.14mm,0.17mm, 0.21mm 0.30mm 876mm 838mm 842mm DR8 TH550 TS260 TS275  Electrolytic Tin Plate 5

Production Process

Prime Electrolytic Tinplate 0.14mm,0.17mm, 0.21mm 0.30mm 876mm 838mm 842mm DR8 TH550 TS260 TS275  Electrolytic Tin Plate 6

PARTNER

Prime Electrolytic Tinplate 0.14mm,0.17mm, 0.21mm 0.30mm 876mm 838mm 842mm DR8 TH550 TS260 TS275  Electrolytic Tin Plate 7

CERTIFICATE

Prime Electrolytic Tinplate 0.14mm,0.17mm, 0.21mm 0.30mm 876mm 838mm 842mm DR8 TH550 TS260 TS275  Electrolytic Tin Plate 8
Information Required with orders and inquirys
Orders and inquiried shall be accompanied by the following information.
1. products name and grade
2.coaing and mass( for Tinplate only),temper grade,finish, and products size.
3.rolling direction
4.quantity
5.application and delivery date
6.number of sheets per packaging( for cut to length products)
7.inside diameter amd maximum acceptable unit coil weight (for coils products).
8.film type,color, contents,and other details of use and environment.
9.other special requirements,if any.
